NetIPC 3000/XL Programmer's Reference Manual (5958-8600)

182 AppendixB
Cause and Diagnostic Codes
Diagnostic Codes in X.25 Clear Packets
Diagnostic Codes in X.25 Clear Packets
The following lists the diagnostic codes (in decimal) sent and received in
X.25 clear packets. You can include cause and diagnostic codes with the
IPCCONTROL or IPCSHUTDOWN intrinsics that will be included in the clear
packet sent by the X.25 protocol. This function is only available with
SVCs.
Table B-1 Diagnostic Codes Sent/Received in Clear Packets
Diagnostic Code Meaning/Cause
0 No additional information
48 Timer expired
65 (1) Invalid facility code used.
(2) the facility requested is not supported or allowed here:
• Reverse charge in CALL CONF packet.
• Fast select.
• Throughout class negotiation (not configured).
• Closed User Group facility in CALL CONF packet (not allowed).
• Bilateral closed user group (not supported).
• Packet size negotiation (not configured).
• Window size negotiation (not configured).
• RPOA facility (not supported).
70 Incoming call barred. The configuration does not allow a call from this
address.
71 No logical channel available.
160 DTE specific. The facility set used does not allow acceptance of a reverse
charge call
231 NSAP unreachable. The requested socket is unavailable.
233 Greater than 30,000 bytes of data were received.
241 A normal disconnect has occurred where the IPC user did not specify a
diagnostic code.
