Appendix E 255
CD-ROM Resources
Adding a CD-ROM Drive
recognizes them. Example hardware configuration paths for HP-IB CD-ROM drives
are shown below. Note the paths for your drives are likely to have different values,
but the paths listed in your MAPPER output need to match the paths you entered with
the AD command in the SYSGEN IO configurator.
Type
Path Component Name ID
----------------------------- ------
52.3.0 CD-ROM Drive HPA1999A
52.4.0 CD-ROM Drive HPA1999A
ODE>EXIT
• If you are on a 4.0 or 4.5 system:
— Please ensure that all peripherals are powered on before you run IOMAP. If a
peripheral is not powered on, it will not appear on IOMAP as an I/O component.
— If you need information about hardware device IDs, print the file
IODFAULT.PUB.SYS to your screen. This file contains ID numbers and associated
parameters for hardware devices. You can display this file when the system is up
and you have the system prompt.
ISL>IOMAP
The system a screen similar to:
IOMAP Revision 2817 April 26, 1988
IOMAP Running: ce81
This program has the capability to identify the configuration of
the system and its I/O paths and devices. Many of the components
of the I/O system can be tested with selftest and loopback
diagnostics.
.
.
.
Do you wish to modify any program parameters? N
Record or print the I/O configuration table displayed on the screen.
This display shows all path names of the I/O components. These pathnames will be
needed later to add to the SYSGEN I/O configuration. This screen is a sample of an
IOMAP from an HP 3000 Series 950 system. The IOMAP display on your screen may
differ significantly from the one below.
Identify: Loop 1: All I/O components are being....
Processor Identification:
.
.
.
Type SW Rev Tests
Path Component Name ID Mod Hdwr Firm Avail
______ ___________________________ ___ ___ ___ ___ ___
0 Memory Controller 1H 9H 2 0 LB
2 Bus Converter 7H CH 2 0
