SNA Node and Link Configuration
Data Required from the Host Configuration
SNA/Token Ring Information
For the host and the HP 3000 to communicate, you must coordinate the
SNA/Token Ring node configuration with the ACF/NCP and
ACF/VTAM host configurations. The HP SNA Products Remote System
Configuration Guide explains these configurations. Table 2-7 shows the
relationships between items from the host configuration and items in
the SNA node configuration file for an SNA/Token Ring link. Each
NMMGR screen field is described later in this chapter.
Table 2-7 Host Macro Values for Token Ring
Host Configuration
Macro and Operand
Field in NMMGR Screen NMMGR Screen Name
LINE LOCADD Remote Station Address Token Ring Link Data
PU
puname
SNA Node Name Configuration
New Name Configuration
IDBLK ID BLK PU Data
IDNUM ID NUM PU Data
MAXDATA MAX DATA PU Data
LU
luname
LU Name LU Data
LOCADDR LU# LU Data
