SNA Link/iX Node Managers Guide (30291-90009)

Chapter 2 35
SNA Node and Link Configuration
Data Required from the Host Configuration
SNA/X.25 Information
For the host and the HP 3000 to communicate, you must coordinate the
SNA/X.25 node configuration with the host configuration. The HP SNA
Products Remote System Configuration Guide explains this
configuration.
Table 2-2 shows the relationships between items from the host
configuration and items in the SNA node configuration file for
permanent virtual circuits (PVCs). Each NMMGR screen field is
described later in this chapter.
Table 2-3 shows the relationships between items from the host
configuration and items in the SNA node configuration file for switched
virtual circuits (SVCs) of an SNA/X.25 link. Each NMMGR screen field
is described later in this chapter.
Table 2-2 Host Macro Values for X.25 Link PVC
Host Configuration
Macro and Operand
Field in NMMGR Screen SNA Node NMMGR Screen
X25.LINE TYPE Virtual Circuit Type X.25 Link Data
X25.PU puname SNA Node Name Configuration
New Name Configuration
PUTYPE Node Type PU Data
MAXDATA MAX DATA PU Data
X25.LU luname LU Name LU Data
LOCADDR LU# LU Data
