SNA Link/iX Node Managers Guide (30291-90009)

116 Chapter5
SNA Link Troubleshooting
Using NMDUMP for the SNA Links
SDLC Link Output Formats
For the SDLC link, NMDUMP formats tracing records and logging
records. When NMDUMP displays the list of subsystems and IDs, and
prompts you for the IDs you want to select, specify the ID for SDLC
Link: 27. Then, proceed normally with NMDUMP. The format of the
tracing records is shown below.
Tracing Records
Figure 5-3 is a partial example of the format of a tracing record for the
SDLC link.
Figure 5-3 SDLC Link Tracing Record Format Example
ref =
1.1
08:44:38:591 Start of Trace diff
= 9999:999
SAT, FEB 29, 1992
$0000: 00 00 00 02 C0 00 00 00 00 00 00 00 FC 08 00 00 ................
$0010: 00 1D 7C 9F F7 6B 64 45 00 00 00 00 00 00 00 00 ..|..kdE........
$0020: 00 02 02 08 80 00 00 00 00 00 00 00 FC 08 00 00 ................4
$0030: 57 41 4E 5F 53 44 4C 43 5F 44 52 49 56 45 52 20 WAN_SDLC_DRIVER
$0040: 20 20 20 20 20 20 20 20 41 30 30 31 30 30 36 33 A002063
$0050: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ................
$0060: 00 00 00 00 00 00 00 D8 20 20 20 20 20 20 20 20 ........
$0070: 00 00 00 07 4E 45 57 59 4F 52 4B 33 20 20 20 20 ....NEWYORK3
$0080: 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20
$0090: 20 20 20 20 FF FF FF C5 00 00 00 00 00 00 00 00 ............
$00A0 SAME BYTE $00: TO $00C0-1 NOT SHOWN: #32
$00C0: 00 00 00 00 00 00 00 00 00 00 00 00 02 AE A5 40 ...............@
$00D0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ................
$00E0 SAME BYTE $00: TO $013C-1 NOT SHOWN: #92
ref =
1.2.6
08:44:41:530 Receive from Remote diff
= 0:797
SAT, FEB 29, 1992 SNRM (P) Addr=$C1 len =
2
$0000: C1 93 Al
ref =
1.77
08:44:41:530+ Driver Mid-plane State-Change diff
= 0:000
SAT, FEB 29, 1992
$0000: 00 00 00 00
