Table 1-1: Mechanical and System Components
Item Description Spare Part Number
Mechanical Components
1 Chassis, 4U, with backplane 229198-001
2 Bezel blank 229208-001
3 Interconnect blank 229200-001
System Components
4 AC power supply assembly, 499 W 212398-001
5 Blower 123482-001
Boards
6 2-Port Shared Storage Module for HP StorageWorks Modular Smart Array 500
system
229205-001
7 Controller 229202-001
8 Power button/LED assembly 229201-001
9 Cache module, DIMM, SDRAM, 128 MB, with battery * 171387-001
Miscellaneous
10 AC power cord * 187335-001
11 Return kit * 249670-001
Options
12 4-Port Shared Storage Module for MSA500 system * 300867-001
13 DC power supply, -48 V * 243791-001
14 Cache module, DIMM, SDRAM, 256 MB, with battery * 262012-001
15 Universal hard drive, 1-inch * 177986-001
16 Universal Hot-Plug Tape drives *
a) AIT, 50/100-GB capacity
b) AIT, 35/70-GB capacity
c) DDS-4, 20/40-GB capacity
190716-001
218575-002
230203-001
17 M-Series Rack Rail option * 314635-001
* Not shown
