Component Identification
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide 4-5
2-Port Shared Storage Module LEDs
1 2 3
Table 4-5: 2-Port Shared Storage Module LEDs
Item LED Description Status
1 Power Green = Power on
Off = Power off
2 SCSI host port A
3 SCSI host port B
Flashing green = On/Activity
Off = Off
