Maintenance and Service Guide
Table Of Contents
- Product features
- Illustrated parts catalog
- Routine care, SATA drive guidelines, and disassembly preparation
- Removal and replacement procedures
- Computer Setup (F10) Utility
- Using HP PC Hardware Diagnostics
- Troubleshooting without diagnostics
- Safety and comfort
- Before you call for technical support
- Helpful hints
- Solving general problems
- Solving power problems
- Solving hard drive problems
- Solving audio problems
- Solving printer problems
- Solving keyboard and mouse problems
- Solving hardware installation problems
- Solving network problems
- Solving memory problems
- Solving USB flash drive problems
- Solving Internet access problems
- Solving software problems
- Backing up, restoring, and recovering
- POST error messages and diagnostic front panel LEDs and audible codes
- Password security and resetting CMOS
- Power cord set requirements
- Statement of memory volatility
- Specifications
- Index
2 Illustrated parts catalog
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Item Description
(1) Rear access cover
(2) Front access cover
(3) Speaker Kit
(4) System board (available for models with UMA graphics memory and discrete graphics memory; UMA model shown)
(5) Right fan
(6) Left fan
(7) Graphics card
(8) Heat sink for use in models with UMA graphics memory
