Maintenance and Service Guide
Table Of Contents
- Product features
- Illustrated parts catalog
- Routine care, SATA drive guidelines, and disassembly preparation
- Removal and replacement procedures
- Computer Setup (F10) Utility
- Using HP PC Hardware Diagnostics
- Troubleshooting without diagnostics
- Safety and comfort
- Before you call for technical support
- Helpful hints
- Solving general problems
- Solving power problems
- Solving hard drive problems
- Solving audio problems
- Solving printer problems
- Solving keyboard and mouse problems
- Solving hardware installation problems
- Solving network problems
- Solving memory problems
- Solving USB flash drive problems
- Solving Internet access problems
- Solving software problems
- Backing up, restoring, and recovering
- POST error messages and diagnostic front panel LEDs and audible codes
- Password security and resetting CMOS
- Power cord set requirements
- Statement of memory volatility
- Specifications
- Index
Base unit side components
Components
(1) Fingerprint reader (3) USB Type-C Thunderbolt™ port with HP Sleep
and Charge
(2) Audio-out (headphone)/Audio-in
(microphone) combo jack
(4) USB SuperSpeed port with HP Sleep and
Charge
Base unit rear components
Components
(1) USB SuperSpeed Plus ports (4) (5) Power connector
(2) HDMI port (6) RJ-45 (network) jack
(3) DisplayPort Out (7) Security cable slot
(4) DisplayPort In
2 Chapter 1 Product features
