3. Remove the eight T20 screws attaching the scan path assembly to the frame. Use a screwdriver
extension for easier screw access.
WARNING! Failure to remove the screws attaching the scan path assembly to the frame could
seriously damage the printer.
NOTE: The screws located at the back, are less accessible and may require a longer screwdriver.
4. Remove tape from the window and open the carriage access door, remove the T30 screw securing
the carriage.
18 Chapter 4 Set up the printer in the final position ENWW
