DTV mode
Resolution Component HDMI/DisplayPort (DTV)
480i o x
576i o x
480p o o
576p o o
720p o o
1080i o o
1080p o o
NOTE: HDMI/DisplayPort input mode may identified in PC resolution: 640 x 480 / 60 Hz, 1280 x
720 / 60 Hz, 1920 x 1080 / 60 Hz or DTV resolutions: 480p, 720p, 1080p.
NOTE: Vertical frequency: To enable the user to watch the product display, screen image should be
changed tens of times every second like a fluorescent lamp. The vertical frequency or refresh rate is
the times of image display per second. The unit is Hz.
Horizontal frequency: The horizontal interval is the time to display one vertical line. When 1 is divided
by the horizontal interval, the number of horizontal lines displayed every second can be tabulated as
the horizontal frequency. The unit is kHz.
IR codes
All models do not support the HDMI/USB function.
Some key codes are not supported depending on the model.
Code (Hexa) Function Note
95 Energy Saving R/C BUTTON
08
POWER R/C BUTTON (ON/OFF)
0B INPUT R/C BUTTON
C4 Display On R/C BUTTON
C5 Display Off R/C BUTTON
43 MENU R/C BUTTON
40 UP (∧) R/C BUTTON
41 Down (∨) R/C BUTTON
07 Left (<) R/C BUTTON
06 Right (>) R/C BUTTON
44 OK R/C BUTTON
28 BACK
R/C BUTTON
5B EXIT R/C BUTTON
72 Appendix A Specifications
