Recognizing preset display resolutions
The display resolutions listed below are the most commonly used modes and are set as factory
defaults. This display automatically recognizes these preset modes and they will appear properly
sized and centered on the screen.
Preset Pixel format Horizontal Frequency (Hz) Vertical Frequency (Hz)
1 640 x 480 31.469 59.940
*2 720 x 400 31.469 70.087
3 800 x 600 37.879 60.317
4 1024 x 768 48.363 60.004
5 1280 x 720 45.000 60.000
6 1280 x 800 49.702 59.810
7 1280 x 1024 63.981 60.020
8 1440 x 900 55.469 59.901
9 1600 x 900 60.000 60.000
10 1680 x 1050 65.290 59.954
11 1920 x 1080 67.5 60.00
*RGB mode only
