Shutter Pushes the current slide like drawing or pulling down the blind as it plays to the next slide
Fade In Fades the slide out slowly before playing to the next slide.
When you select Set Video:
▲
Press the Navigation buttons to scroll to make appropriate adjustments.
When you select Set Audio:
1. Press the Navigation buttons to scroll to show the Sound Mode, Clear Voice II, or Balance.
2. Press the Navigation buttons to scroll to make appropriate adjustments.
Listening to music
NOTE: Speakers must be installed on the display to listen to audio.
1. Press the Navigation buttons to scroll to My Media and press OK.
2. Press the Navigation buttons to scroll to Music List and press OK.
3. Press the Navigation buttons to scroll to a folder you want and press OK.
4. Press the Navigation buttons to scroll to a file you want and press OK.
Menu Description
Play marked Display the selected music file.
Mark All Mark all music files on the screen.
Unmark All Deselect all marked music files.
Exit Mark Mode Exit the Mark Mode.
5. Play music.
6. Control playback by using the following buttons.
Button Description
Stops playing back the file and moves back to the music list.
Plays a music file.
Pauses or resumes playback.
Skips to the previous file.
Skips to the next file.
Listening to music 57
