SOF0: baseline
●
SOF1: Extend Sequential
●
SOF2: Progressive
Photo size:
●
Min: 64 x 64
●
Max: 136 x 768
Music: MP3
Bit rate: 32 kbps to 320 kbps
Sampling rate:
●
32 kHz, 44.1 kHz, 48 kHz (MPEG1 L3)
●
16 kHz, 22.05 kHz, 24 kHz (MPEG2 L3)
●
8kHz, 11.025 kHz, 12 kHz (MPEG2.5 L3)
Playing videos
Your display shows all of the video files saved in a USB storage device or shared folder on a
computer.
1. Press the Navigation buttons to scroll to My Media and press OK.
2. Press the Navigation buttons to scroll to Movie List and press OK.
3. Press the Navigation buttons to scroll to a folder you want and press OK.
4. Press the Navigation buttons to scroll to a file you want and press OK.
Menu Description
Play marked Returns to the selected video file.
Mark All Mark all video files on the screen.
Unmark All Deselect all marked video files.
Exit Mark Mode Exit the Mark Mode.
5. Play a video.
NOTE: Non-supported files are displayed in the preview image by icon only .
Abnormal files are displayed in the form of a bitmap
.
6. Control playback by using the following buttons.
Button Description
Stops the playback.
Plays a video.
Pauses or resumes the playback.
Scans backward in a file.
52 Chapter 8 Setting up the display for music, videos, and photos
