Browsing files
Access the photo, music, or video lists and browse files.
1. Connect a USB storage device.
2. Press MENU to access the main menus.
3. Press the Navigation buttons to scroll to My Media and press OK.
4. Press the Navigation buttons to choose from Movie List, Photo List, or Music List and press OK.
Item Description
(1) Moves to upper level folder.
(2) Current page/Total pages.
(3) Corresponding buttons on the remote control.
(4) Current page/total pages of contents under the folder focused on (1).
(5) Contents under the folder focused on (1).
Button Description
Green button Press the green button to toggle between Photo List > Music List, Music List > Movie List or Movie
List > Photo List.
Yellow button A method to view as either large thumbnail folder or listing.
Blue button Convert to Mark Mode.
50 Chapter 8 Setting up the display for music, videos, and photos
