Picture Mode options
Setting Description
Backlight Adjusts the brightness of the screen by controlling the LED backlight. If you
decrease the brightness level, the screen becomes darker and the power
consumption will be reduced without any video signal loss.
Contrast Increases or decreases the gradient of the video signal. You may use Contrast
when the bright part of the picture is saturated.
Brightness Adjusts the base level of the signal in the picture. You may use Brightness when
the dark part of the picture is saturated.
Sharpness Adjusts the level of crispness in the edges between the light and dark areas of the
picture. The lower the level, the softer the image.
Color Adjusts intensity of all colors.
Tint Adjusts the balance between red and green levels.
Color Temp Set to warm to enhance hotter Colors such as red, or set to cool to make picture
bluish.
Advanced Control Customizes the advanced options. Refer to the Advanced image options.
Picture Reset Restores the options to the default setting.
NOTE: If the Picture Mode setting in the Picture menu is set to Vivid, Standard, Cinema, Sport or
Game the subsequent menus will be automatically set.
You cannot adjust color and tint in the RGB/ HDMI-PC/ DisplayPort PC mode.
When using the Smart Energy Saving function, the screen may look saturated in the white area of a
still image.
If Energy Saving is set to Minimum, Medium, or Maximum, the Smart Energy Saving function is
disabled.
Advanced control
Setting Description
Dynamic Contrast (Off/High/ Medium/
Low)
Adjusts the contrast to keep it at the best level according to the brightness of the
screen. The picture is improved by making bright parts brighter and dark parts
darker. (Function works in the following mode - Component, HDMI-DTV,
DisplayPort-DTV)
Dynamic Color (Off/High/Low) Adjusts screen Colors so that they look livelier, richer and clearer. This feature
enhances hue, saturation and luminance so that red, blue, green and white look
more vivid. (Function works in the following mode - Component, HDMI-DTV,
DisplayPort-DTV)
Clear White (Off/High/Low) Make the white area of screen brighter and more white.
Skin Color (-5 to 5) It detects the skin area of video and adjusts it to express a natural skin color.
Noise Reduction (Off/High/ Medium/
Low)
Reduces screen noise without compromising video quality. (Function works in the
following mode - Component, HDMI-DTV, DisplayPort-DTV)
Digital Noise Reduction (Off/High/
Medium/Low)
This option reduces the noise produced while creating digital video signals.
30 Chapter 6 Customizing settings
