PICTURE settings
1. Press MENU to access the main menus.
2. Press the Navigation buttons to scroll to PICTURE and press OK.
3. Press the Navigation buttons to scroll to the setting or option you want and press OK.
4. When you are finished, press EXIT. When you return to the previous menu, press BACK.
Setting Description
Aspect Ratio Changes the image size to view images at its optimal size.
Energy Saving Sets to automatically adjust the screen brightness corresponding to the surroundings.
Level
Off: Disables Energy Saving function.
Minimum/Medium/Maximum: Selects the brightness level of the LED backlight.
Screen Off: The screen turns off in 3 seconds.
Smart Energy
Saving
Adjusts the LED backlight and contrast depending on the screen brightness.
Level
Off: Disables the Smart Energy Saving function.
On: Enables the Smart Energy Saving function to save power consumption as much as the value set in
the smart energy saving rate.
Picture Mode Selects one of the preset image modes or customizes options in each mode for the best display screen
performance. You are also able to customize advanced options of each mode. The available preset
picture modes vary depending on the display.
Mode
Vivid: Adjusts the video image by enhancing the contrast, brightness, Color, and sharpness.
Standard: Adjusts the image for the normal environment.
Cinema: Optimizes the video image for a cinematic look to enjoy videos.
Sport: Optimizes the video image for high and dynamic actions by emphasizing primary Colors such as
white, grass, or sky blue.
Game: Optimizes the video image for a fast gaming screen such as computers or games.
SCREEN (In RGB
Mode Only)
Customizes the computer display options in RGB mode.
Option
Resolution: Selects a proper resolution. See
Customizing settings on page 28.
Auto Configure: Sets to adjust the screen position, clock, and phase automatically. The displayed image
may be unstable for a few seconds while the configuration is in progress.
Position/Size/Phase: Adjusts the options when the picture is not clear, especially when characters are
shaky, after the auto configuration.
Reset: Restores the options to the default setting.
Accessing main menus 29
