6 Customizing settings
Accessing main menus
1. Press MENU to access the main menus.
2. Press the Navigation buttons to scroll to one of the following menus and press OK.
3. Press the Navigation buttons to scroll to the setting or option you want and press OK.
4. When you are finished, press EXIT. When you return to the previous menu, press BACK.
Item Function Description
(1) PICTURE Adjusts the image size, quality, or effect
(2) AUDIO Adjusts the sound quality, effect, or volume level.
(3) TIME Sets the time, date, or Timer feature.
(4) OPTION Customizes the general settings
(5) NETWORK Sets up the network.
(6) MY MEDIA Display and play video, photo and music content stored on your USB.
28 Chapter 6 Customizing settings
