Customizing sound options
Customize options of each sound mode for the best sound quality.
1. Press MENU to access the main menus.
2. Press the Navigation buttons to scroll to AUDIO and press OK.
3. Press the Navigation buttons to scroll to Sound Mode and press OK.
4. Press the Navigation buttons to scroll to an image mode you want and press OK.
5. Select and adjust following options, and then press OK.
Option Description
Infinite sound Provides 5.1 channel stereo sound from two speakers.
Treble Controls the dominant sounds in the output. When you turn up the treble, it will increase the
output to the higher frequency range.
Bass Makes the output sound softer. If the bass is increased, the frequency of the output also
increases.
Reset Resets the sound mode to the default setting.
6. When you are finished, press EXIT. When you return to the previous menu, press BACK.
Using additional options
Using the input list
Selecting an input source
1. Press INPUT to access the input source list.
2. Press the Navigation buttons to scroll to one of the input sources and press OK.
Input Source Description
AV Watch the contents in a DVD or other external devices, or through a digital set-top box.
Component Watch the contents in a DVD or other external devices, or through a digital set-top box.
RGB View a computer display on the screen.
HDMI Watch contents in a computer, DVD, or digital set-top box or other high definition devices.
DisplayPort Watch contents in a computer, DVD or digital set-top box other high definition devices.
VOE Watch contents through the Ethernet port.
USB Plays the multimedia files saved in the USB.
Input label adjustment
Selecting input labeling
The digital inputs may be set to PC or DTV input labels (HDMI, DisplayPort or VOE). The PC input
label allows limited aspect ratio (16:9, 1:1 or 4:3). The DTV input label provides adjustment
capabilities for zoom, Just Scan, sharpness, color, and tint control.
24 Chapter 5 Using the display
