Adjusting the screen
Selecting an image mode
Display images in its optimized settings by selecting one of the preset image modes.
1. Press MENU to access the main menus.
2. Press the Navigation buttons to scroll to PICTURE and press OK.
3. Press the Navigation buttons to scroll to Picture Mode and press OK.
4. Press the Navigation buttons to scroll to an image mode you want and press OK.
Option Description
Vivid Adjusts the video image by enhancing the contrast, brightness, Color, and sharpness.
Standard Adjusts the image for the normal environment.
Cinema Optimizes the video image for a cinematic look to enjoy videos.
Sport Optimizes the video image for high and dynamic actions by emphasizing primary Colors such as
white, grass, or sky blue.
Game Optimizes the video image to enjoy dynamic image when playing a game.
5. When you are finished, press EXIT. When you return to the previous menu, press BACK.
Customizing image options
Customize basic and advanced options of each image mode for the best screen performance.
1. Press MENU to access the main menus.
2. Press the Navigation buttons to scroll to PICTURE and press OK.
3. Press the Navigation buttons to scroll to Picture Mode and press OK.
4. Press the Navigation buttons to scroll to an image mode you want and press OK.
5. Select and adjust the following options, and then press OK.
Option Description
Backlight Adjusts the brightness of the screen by controlling the LED backlight. If you decrease the brightness
level, the screen becomes darker and the power consumption will be reduced without any video
signal loss.
Contrast Increases or decreases the gradient of the video signal. You may use Contrast when the bright part
of the picture is saturated.
Brightness Adjusts the base level of the signal in the picture. You may use Brightness when the dark part of the
picture is saturated.
Sharpness Adjusts the level of crispness in the edges between the light and dark areas of the picture. The lower
the level, the softer the image.
Color Adjusts intensity of all colors.
Tint Adjusts the balance between red and green levels.
Color temp. Set to warm to enhance hotter Colors such as red, or set to cool to make picture bluish.
22 Chapter 5 Using the display
