Remote control buttons
Item Button Function Item Button Function
(1) Power Turns the display on or off. (7) MUTE Mutes all sound.
(2) MONITOR
ON/OFF
Turns off the display then turns
it back on.
(8) ENERGY
SAVING
Adjusts the brightness on the screen
to reduce energy consumption.
(3) MARK Selects a specific file in USB
mode.
(9) INPUT Selects Input mode.
(4) ARC Selects the aspect ratio. (10) Number and
alphabet
buttons
Enters numerical or alphabetical
characters depending on the setting.
(5) Volume up/
down
Adjusts the volume level. (11) BRIGHTNESS
key
Adjust the brightness by pressing
the Up and Down buttons on the
remote control. In USB mode, the
OSD menu has the Page function to
move to the next file list.
(6) PSM Selects Picture Status Mode.
