Table 37 VCEM server error messages and descriptions (continued)
Error message description
NOTE: The error message descriptions in this table use
[x] to represent variables in the error message output.
Error message number
The server profile cannot be found.6150
Cannot perform the operation. Verify there is at least one
VC Domain Group already created.
6152
The operation could not be completed because the VC
Domain Group is under maintenance.
6153
The selection is not valid. Verify that the selected bay
supports the assign operation.
6156
VCEM cannot perform the requested operation because
the VC Domain Group firmware mode is not supported.
6157
Verify that the VC Domain Group has a supported firmware
mode and perform the operation again. To upgrade the
VC Domain Group firmware mode, perform the following
steps in the VCEM GUI, and then perform the operation
again: 1. For each VC Domain marked with incompatible
status: a. Enable the VC Domain maintenance operation.
b. Upgrade the managed VC Domains to (at least) the
minimum VCEM-supported VC firmware version. c.
Complete the VC Domain maintenance operation. 2.
Upgrade the VC Domain Group firmware mode to (at least)
the minimum supported by VCEM. To update the VC
Domain firmware version, check the HP Insight Software
Support Matrix for the VCEM-supported VC firmware
versions.
The operation could not be performed because the selected
Server Profile contains iSCSI or FCoE connections that are
6158
not supported by VC Domain Group firmware mode
version. Remove the non supported connections from Server
Profile and try the operation again.
Cannot assign server profile because the selected bay is
covered.
6159
Invalid value for VLAN ID (1-4094)6201
85
