Table 37 VCEM server error messages and descriptions (continued)
Error message description
NOTE: The error message descriptions in this table use
[x] to represent variables in the error message output.
Error message number
Invalid FCoE connection port number. Port number must
be greater than 0.
5071
Invalid FC connection port number. Port number must be
greater than 0.
5072
The provided configuration for multiple networks does not
have the minimal number of VNet mappings. At least one
VNet mapping is required.
5073
A server profile must have at least two Ethernet network
connections set with port numbers 1 and 2.
5074
The requested action cannot be performed because the
logged in user has read-only privilege.
6010
An unexpected error has occurred. VCEM cannot proceed
with this task.
6012
VC Domain identifier cannot be found. Verify that a VC
Domain is entered and the VC Domain is managed by
VCEM.
6015
VC Domain Group identifier cannot be found. Verify that
a VC Domain Group is entered and the VC Domain Group
exists in VCEM.
6016
VC Domain identifier cannot be found. Verify that a VC
Domain is entered and the VC Domain is not managed by
VCEM.
6017
The selection is not valid because the selected VC Domain
Group is not available. Verify the selection and perform
the operation again.
6018
The selection is not valid because the selected Server Profile
is not available. Verify the selection and perform the
operation again.
6019
The selection is not valid because the selected bay is not
available. Verify the selection and perform the operation
again.
6020
Bay identifier cannot be found. Verify that a bay is entered
and the associated VC Domain is managed by VCEM.
6050
Bay information could not be found. Verify the provided
bay belongs to a managed VC Domain and the External
Manager lock on the VC Manager is active.
6051
Missing VC Domain Group name. Fill in the VC Domain
Group name with a unique and valid name. Names can
6062
only have alphanumeric characters, hyphens (-) or
underbars (_) and are limited to 64 characters.
The operation cannot be performed because the VC
firmware version for the selected VC Domain(s) is not
6070
supported by VCEM. Refer to the VCEM User Guide to
verify the supported VC firmware versions, and then update
the VC Domain(s) firmware to a supported version.
Server Profile identifier cannot be found. Verify that a server
profile is entered, the associated VC Domain is managed
by VCEM and the server profile exists in VCEM.
6114
84 Error messages
