Table 37 VCEM server error messages and descriptions (continued)
Error message description
NOTE: The error message descriptions in this table use
[x] to represent variables in the error message output.
Error message number
VCEM cannot perform the operation because the database
server is not responding. Possible causes are: - No
2812
connectivity with the database server (in case a remote
database). - Too many database operations being
performed at the same time. To resolve this, verify that the
database server is running and can be accessed through
the CMS. Wait until all VCEM jobs are complete, and then
perform the operation again.
Error logging in.2813
User name can not be empty.5010
Password can not be empty.5011
Specified job ID must be greater than 0 and valid.5014
Invalid profile network connection speed type.5021
Invalid network connection PXE setting.5022
Invalid FC connection topology.5023
Invalid FC connection boot priority.5024
Invalid network connection port number. Port number must
be greater than 0.
5028
Invalid network connection port number. Port number
cannot be duplicated.
5029
Invalid FC connection connection bay. Connection bay
number must be greater than 2.
5032
Invalid FC connection connection bay. Verify that the VC
Domain has an FC module on this connection bay.
5033
Could not locate the specified server bay. Make sure the
enclosure name and bay name are valid
5046
Could not locate the specified server profile. Make sure
the server profile ID is valid.
5047
No valid server bay is found. Verify that the bay ID is valid.5049
Error logging in. Incorrect user name or password.5050
Only one VLAN pair can be set as untagged.5063
Invalid iSCSI connection port number. Port number must
be greater than 0.
5064
Invalid iSCSI connection port number. Port number cannot
be duplicated.
5065
Invalid iSCSI connection boot priority.5066
Invalid profile iSCSI connection speed type.5067
Invalid FCoE connection connection bay. Verify that the
VC Domain has an FCoE module on this connection bay.
5068
Invalid FCoE connection boot priority.5069
Invalid profile FCoE connection speed type.5070
