Table 37 VCEM server error messages and descriptions (continued)
Error message description
NOTE: The error message descriptions in this table use
[x] to represent variables in the error message output.
Error message number
SAN boot settings for each FC SAN connection physical
port
There are missing or duplicate Ethernet network
connections. A continuous sequence finishing on the last
valid Ethernet network connection port is required.
2610
The specified VC Domain Group does not exist. A server
profile must be assigned to an existent VC Domain Group.
2611
Cannot perform server profile assignment because the
specified VC Domain has an expired license. Apply a
permanent license and then perform the operation again.
2612
Cannot perform server profile assignment because the
target Server Bay is already in use by another server
profile.
2613
Cannot perform the Server Profile operation because there
is a server bay with a server powered up. Verify that all
2614
servers involved in the operation are powered down, and
then perform the operation again.
Cannot perform server profile assignment because the
specified target Server Bay is not valid. Verify the specified
target Server Bay belongs to a managed VC Domain.
2615
Cannot perform server profile assignment because the
server profile is already assigned to another Server Bay.
2616
The assignment was triggered explicitly, or this profile was
either (a) failed over, (b) moved, or (c) edited.
Cannot perform server profile unassignment because an
exception occurred.
2618
Cannot perform server profile unassignment because the
specified server profile is not currently assigned to a server
bay.
2619
Cannot perform the operation because the VC Domain
maintenance is not completed. Perform these steps: 1. Go
2620
to the VCEM - VC Domains tab and select the VC Domain
that is under maintenance. 2. Click VC Domain
Maintenance. 3. Click Complete VC Domain Maintenance
to apply the configuration changes to the entire VC Domain
Group, or click Cancel to not apply changes and restore
the current VC Domain Group configuration to the VC
Domain. Verify that the VC Domain maintenance operation
was completed or canceled with success, and then perform
the operation again.
The number of FC SAN connections is incorrect.2625
In the FC SAN connection for interconnect bay , the range
type is not compatible with the addresses inside the
connection.
2626
A server profile cannot have less than two Ethernet network
connections. At least two Ethernet network connection
physical ports are required.
2627
In the FC SAN connection for interconnect bay , the
connection was replaced by a new one. To replace a
2628
connection by a new one, first edit the profile and delete
75
