Table 37 VCEM server error messages and descriptions (continued)
Error message description
NOTE: The error message descriptions in this table use
[x] to represent variables in the error message output.
Error message number
The operation cannot be performed because VC Domain
firmware version [x] is incompatible with VC Domain Group
2420
firmware mode [x]. Refer to the VCEM User Guide to verify
the VC firmware versions supported by each VC Domain
Group firmware mode.
The enabled VC feature(s) [x] are blocking the addition of
VC Domain [x] to the VC Domain Group. Verify how to
2421
disable VC features according to VC Domain Group
firmware mode in the VCEM User Guide.
The operation cannot be performed because the Server
Profiles [x] are using an invalid untagged VLAN. Refer to
2425
the VCEM User Guide troubleshooting section for
information on how to use untagged VLANs in Server
Profiles.
The operation cannot be performed because the VC
Domain [x] is no longer configured. To continue managing
2426
this VC Domain with VCEM, remove the VC Domain from
the VC Domain Group, and then add it back to the VC
Domain Group.
The operation cannot be performed because the VC
Domain [x] was upgraded a firmware version that does
2430
not provide backward compatibility with the VC Domain
Group firmware mode [x]. To continue managing this VC
Domain with VCEM, use the complete VC Domain
maintenance operation and after that, upgrade all the
remaining VC Domains inside the VC Domain Group to a
firmware version that is compatible among them.
Server profile name is empty or invalid. Names can only
have alphanumeric characters, hyphens (-) or underbars
(_) and are limited to 64 characters.
2551
Server profile name is duplicate. Another server profile
with the same name already exists in VCEM.
2552
There are more than one network interfaces (NIC)
configured with PXE enabled. Only one NIC in the profile
can be PXE enabled.
2553
Cannot remove network connection. Verify: 1- The provided
connection exists. 2- The provided port number is different
2554
from 1 or 2. 3- The provided connection is the last one in
the network connections list.
Cannot find network connection for the specified port
because the port number is invalid. Verify there is a
connection for the provided port number.
2555
Cannot create network connection because the specified
network does not exist. Enter a valid network name.
2556
In the FC SAN connection for interconnect bay , the
selected FC SAN fabric does not exist. The provided FC
2557
SAN fabric must exist in the VC Domain group the Server
profile belongs.
Cannot create a network connection for the entered port.
Ethernet network connections require a valid network. Verify
2559
73
