Table 36 VCEMCLI error messages and descriptions (continued)
Error message descriptionError message number
Failed to initialize XML parser124
Failed to create the export file140
Invalid path specified for the export file141
Export file name is too long. Maximum length is 260
characters
142
Failed to find server profile data structure key. Column
alignment may be affected
144
Duplicate key found while mapping server profile. Column
alignment may be affected
145
Invalid speed for FC connection160
Invalid speed for FCOE connection170
No help information available200
Unable to get job225
VCEM job ID does not exist.226
Operation timed out242
VC Domain Group does not exist.260
Failed to assign profile to bay in enclosure261
Failed to unassign profile262
No managed element defined for the profile operation264
Server profile does not exist265
Port is not available in server profile267
Port number is invalid for profile. The port number must be
greater than zero
268
Internal error: Invalid connection type in profile object
m_size call
269
There are no more connections in profile available for
removal
270
Cannot find the server port network mapping for network280
There are no network connections available for removal281
Table 37 VCEM server error messages and descriptions
Error message description
NOTE: The error message descriptions in this table use
[x] to represent variables in the error message output.
Error message number
VCEM received an unexpected error from VC Manager.
Verify that VC Manager is working properly and perform
1999
the operation again. The exception received from VC API:
[x].
The VC Domain Group cannot be created because unique
configuration of the VC Domain could not be retrieved for
2006
VC Domain [x]. Possible causes are: a failure to connect
to the VC Domain or VCEM has no lock on the VC Domain.
Verify that the VCEM can communicate with the VC Domain
67
