4 Error messages
To help you troubleshoot symptoms, Table 36 and Table 37 (page 67) displays error message
numbers and descriptions.
Table 36 VCEMCLI error messages and descriptions
Error message descriptionError message number
Unable to expand environment variable because the
expanded string is too large
10
Unable to expand environment string11
Failed to convert argument to a boolean representation12
Failed to convert argument to a numeric representation13
Argument is invalid20
Multiple subcommands found21
Missing subcommand22
Password argument not found23
Unsupported managed element for subcommand24
Subcommand not implemented:25
Unsupported managed element for subcommand27
Corresponding value for argument was not found28
Corresponding value for argument was not found30
Invalid result from getArgPair31
Index out of range32
Unsupported managed element for subcommand33
Command line value found without an identifying keyword47
Cannot use SIM certificate authentication with a non-local
host
48
Argument contains invalid value. Passwords must contain
12 to 16 ASCII characters
49
Argument contains invalid value50
Invalid log level100
Failed to create log file103
Invalid path specified for file104
Log file name is too long. Maximum length is 260
characters
105
Logging system internal error106
Help file not found107
Warning: Failed to get current system time. Command
execution will not timeout
120
Failed to get username from system.121
Failed to initialize the XML parser123
66 Error messages
