add server-port-map
The -add server-port-map command adds new server port network mapping, and allows
server ports to be shared among multiple VC Ethernet networks.
NOTE: The -add server-port-map command cannot be used if the domain setting
VLanTagControl is currently set to tunnel. This restriction is lifted for VC Domain Groups
running VC 3.30 firmware mode and above.
Syntax
-add server-port-map –profileName <profileName>
-portnumber <portNumber>
-network <NetworkName>
[-uplinkset <Uplink Set Name>]
[-vlanid <VLan Id>]
[-untagged <true|false>]
Parameters
Table 24 Parameter descriptions for -add server-port-map
OptionalRequiredDescriptionParameter
xThe name of an existing
profile to add the
server-port-map to.
-profilename
xThe name of the port to add
the server-port-map to.
-portnumber
xThe name of a valid network
to which the mapping will
be added.
NOTE: A network can be
configured once for every
profile connection and every
profile connection can be
configured for a maximum
of 28 networks.
-network
x
NOTE: If the domain
setting
sharedservervlanid is
set to true, then the
Uplinkset is a required
value.
The name of the shared
uplinkset.
-uplinkset
x
NOTE: If the uplinkset
name is specified, then the
vLanid property should not
be specified, since the server
VLAN ID will be forced to be
same as the VLAN ID used
when adding the network to
the shared uplinkset.
-vlanid
xEnables or Disables the
network to handle untagged
-untagged
packets. Only one network
in an enet-connection can be
made to handle untagged
