set iscsi-boot-param
The -set iscsi-boot-param command configures the basic iSCSI boot parameters on the
specified iSCSI connection.
Syntax
-set iscsi-boot-param
–profilename <profileName>
-portnumber <PortNumber>
-bootorder <Primary|Secondary|Disabled|USEBIOS>
[-lun <Logical Unit number>]
[-initiatorname <Initiator name>]
[-initiatorip <IP address>]
[-mask <Netmask>]
[-gateway <Gateway>]
[-vlanid <Vlan Id>]
[-targetname <Target Name>]
[-targetip <Primary Target IP>]
[-targetport <Primary Target Port>]
[-targetip2 <Alternate Target IP>]
[-targetport2 <Alternate Target Port>]
[-authentication <None|CHAP|CHAPM>]
[-username <username>]
[-secret <secret password>]
[-mutualusername <username>]
[-mutualsecret <Mutual secret password>]
[-iscsibootparamdhcp <enabled|disabled>]
[-networkparamdhcp <enabled|disabled>]
[-dhcpvendorid <VendorID>]
Parameters
Table 22 Parameter descriptions for -set iscsi-boot-param
OptionalRequiredDescriptionParameter
xThe name of the profile
associated with the
iscsi-boot-param.
-profilename
xThe number of the port for
this set of parameters.
-portnumber
xEnables or disables iSCSI
boot. Selecting primary,
-bootorder
secondary or usebios
will result in the iSCSI boot
being enabled. The default
selection for this attribute is
disabled.
xThe Logical Unit Number
(LUN) of the Target identifies
-lun
the volume to be accessed.
Valid values for standard
LUNs are 0-255 decimal.
Valid values for extended
LUNs are 13 to 16 character
hexadecimal values. The
default value is zero.
