HP Virtual Connect Enterprise Manager 6.3.1 CLI Guide
Table Of Contents
- HP Insight Software Virtual Connect Enterprise Manager
- Contents
- 1 Getting Started
- 2 Using VCEMCLI
- 3 Using VCEM commands
- add profile
- set profile
- assign profile
- export profiles
- unassign profile
- add enet-connection
- set enet-connection
- remove enet-connection
- add fc-connection
- set fc-connection
- remove fc-connection
- add fcoe-connection
- set fcoe-connection
- remove fcoe-connection
- add iscsi-connection
- set iscsi-connection
- remove iscsi-connection
- set iscsi-boot-param
- remove iscsi-boot-param
- add server-port-map
- set server-port-map
- remove server-port-map
- poweroff devicebay
- poweron devicebay
- show power-status
- show job
- show version
- show vcem-status
- startvcdmaint
- cancelvcdmaint
- completevcdmaint
- 4 Error messages
- 5 Troubleshooting VCEMCLI
- VCEMCLI calls result in access denied errors
- VCEMCLI calls result in errors for invalid leading character or invalid characters
- VCEMCLI calls result in 404 errors
- API timeouts
- High CPU usage on the CMS server while running a VCEMCLI client
- Job reports failed status
- Completed with warning job status
- Unable to assign a profile to a Domain Group
- VC Domain reports Configuration Mismatch status
- VC Domain reports Expired License status
- Error on database operation occurs
- Failed to execute VCEM operation because VC firmware not supported
- Creating a server profile fails
- Server profile edit operation fails when target server is powered on
- Server profile job completed with success but changes have not occurred
- After a server profile assignment, some connections defined in the server profile are not functional
- Commands -add profile or -set profile error messages
- Command -add profile error messages
- Additional Troubleshooting Information and tools
- 6 Support and other resources
- Index
add enet-connection
The -add enet-connection command is used to add a new Ethernet network connection to
an existing server profile in the VC Domain.
NOTE: The maximum number of Ethernet connections that can be added to a server profile
depends on the Virtual Connect firmware version. For more information, see the HP Virtual Connect
Enterprise Manager 6.3.1 User Guide.
Syntax
-add enet-connection –profilename <profileName>
[-network <NetworkName>]
[–pxe <enabled|disabled|usebios>]
[–speedtype <auto|preferred|custom>]
[–speed <speed>]
Parameters
Table 8 Parameter descriptions for -Add enet-connection
OptionalRequiredDescriptionParameter
xThe name of an existing
profile to which the
connection is added.
-profilename
xThe name of an existing
network to associate with the
-network
connection. If the network
name is not specified, or is
set to unassigned, then
the network will be left
unassigned and can be
assigned later.
xEnables or disables PXE on
the network connection. If
-pxe
this value is not specified,
the default will be Usebios.
NOTE: Only one
connection can have PXE
enabled per profile.
24 Using VCEM commands
