IMPORTANT: When you perform a VC Server Profile Failover, no reference is provided to the
VC Domain from Systems Insight Manager. To access this reference, you must correlate the Systems
Insight Manager and Virtual Connect logs. For more information, see “Correlating VCEM operations
in Systems Insight Manager and Virtual Connect logs” (page 58).
VCEM detects the presence of logical server managers or upper level managers. When performing
this task, a prompt dialog message appears and explains the impact of performing that task from
outside the logical server manager or upper level manager. The following message appears:
IMPORTANT: VCEM has detected you may be using other products, such as
HP Insight Dynamics – VSE. Performing a failover of a Server Profile
to a designated spare blade may make it inconsistent with the upper
level manager. It is recommended to use the upper level manager to edit
this Server Profile. Type YES to proceed with this operation.
Preconditions for VC Server Profile Failover
• Source and designated spare servers must be part of the same VC Domain.
• Designated spare servers are powered off.
• A spare server must be the same model as the source server.
Using spare bays
For information about designating spare bays, see “Designating spare bays” (page 77).
Initiating VC Server Profile Failover through the VCEM CLI
You can initiate VC Server Profile Failover through the VCEM CLI or GUI.
NOTE: To perform VC Server Profile Failover tasks using the VCEM CLI, you must have Systems
Insight Manager administrative privileges.
To initiate VC Server Profile Failover, enter C:\>VCEM -failover arguments, then enter the
appropriate argument as follows:
• For a bay, enter -bay enclosure_name:bay_number.
• For a host, enter -host hostname.
• For an IP address, enter -ip IP_address.
The host and IP address are valid arguments only when Systems Insight Manager runs on the same
system as VCEM and full server discovery is in operation in Systems Insight Manager.
Server bays are specified by their number. Double-density server bays must be specified with the
bay number followed by the A or B letter such as 12A or 12B.
Double-density server baysSingle-density server baysEnclosure series
1A-8B1-8C3000
1A-16B1-16C7000
Initiating VC Server Profile Failover through the VCEM GUI
1. Select an assigned server profile with an acceptable spare server.
2. Click VC Ser ver Profile Failover. The Virtual Connect Enterprise Manager is
executing the request message appears.
3. Click OK to go to the Jobs page and monitor job progress.
Performing a VC Server Profile Failover 71
