Table 3-5 Role-based privileges
DescriptionPrivileges
This role provides only view-only access to VCEM pages
and is based on the previous VCEM Read Only role.
VCEM User (read only)
This role enables you to perform some of the tasks of the
VCEM Domain Group Operator except for creating,
editing, or deleting a server profile.
VCEM Group Limited Operator
This role enables you to manage server profiles within one
or more specific VC Domain Groups. Only server profile
operations within the chosen VC Domain Group are
permitted.
VCEM Domain Group Operator
This role enables you to manage VC Domains and server
profiles within one or more specific VC Domain Groups.
All operations within the chosen VC Domain Group are
permitted.
VCEM Domain Group Administrator
This role provides access to all VCEM operations and is
formerly known as VCEM Full Access.
VCEM Administrator
Adding a VC Domain to a VC Domain Group
You can select the Add to VCD Group button if there is at least one VC Domain Group created,
and the current selection contains VC Domains that do not belong to VC Domain Groups, and that
have a valid license.
Ensure that the VC Domains you select have a valid VC firmware version. If the VC firmware is
invalid, the following error message is displayed:
The operation cannot be performed because the VC firmware version for
the selected VC Domain(s) is not supported by VCEM. Refer to the VCEM
User Guide to verify the supported VC firmware versions, and then update
the VC Domain(s) firmware to a supported version.
Before adding a VC Domain to a VC Domain Group, verify the VC Domain meets the minimum
requirements as well as the VC Domain Group configuration for the configured VC Domains. For
the complete list of configuration checks, see “Requirements for adding a VC Domain to a VC
Domain Group” (page 27).
To manage multienclosure VC Domains in VCEM, you must perform the following steps before you
add a VC Domain to a VC Domain Group:
1. Log in to Virtual Connect Manager.
2. Find and import a local enclosure, and then select the appropriate Double-dense option.
3. Skip the Network and Fibre Channel configuration wizards, and then navigate directly to the
VC Domain user interface.
4. Find and import the necessary remote enclosures in the correct order through Virtual Connect
Manager.
5. Go to Systems Insight Manager and perform a manual discovery for the Onboard Administrator
IP address of all released VC Domain enclosures.
VCEM cannot manage a VC Domain having one or more FC modules in an Incompatible state.
The FC module can become incompatible in the following situations:
• An HP Virtual Connect 4Gb FC module replaces an HP Virtual Connect 8Gb 24-port FC
module.
• An HP Virtual Connect 8Gb 24-port FC module replaces a HP Virtual Connect 4Gb FC module.
Adding a VC Domain to a VC Domain Group 39
