9. Click the VC Domains tab. VC Domains appear as the following:
• Unconfigured VC Domains—Appear as VCD_name, where name is the temporary name
automatically given to the VC Domain.
• Configured VC Domains—Appear with the VC Domain name.
10. Select a VC Domain, and then click License to license the domain. For more information on
licensing, see “VCEM cabinet licensing”.
11. Create a new VC Domain Group, and then add one or more already licensed VC Domains
to it. For more information on creating a new VC Domain Group, see “Creating a VC Domain
Group”.
IMPORTANT: In a new environment when adding VC Domains to into the VC Domain Group
you must have one configured VC Domain. Any additional VC Domains can remain
non-configured as they are automatically configured by VCEM. For an environment with
existing already configured VC Domains, simply create a VC Domain Group for the VC
Domains.
You can continue using VCEM and its additional functions such as creating server profiles and
assigning them to bays.
VCEM uses a Secure Sockets Layer (SSL) connection provided by HP SIM. For more information
about the available cipher suites and how to enable or disable them, see the Understanding HP
SIM security white paper at http://h18013.www1.hp.com/products/servers/management/hpsim/
infolibrary.html.
VCEM uses the same TCP ports as HP SIM. VCEM does not open any other TCP ports.
Upgrading incompatible firmware modes and versions
If unsupported VC Domain firmware versions are detected at the end of a VCEM 6.2 upgrade, a
warning message similar to the following is displayed:
VCEM detected unsupported VC firmware. For information on how to upgrade your firmware, run the Insight Software
Advisor or refer to the VCEM User Guide troubleshooting section.
Upgrade to a supported VC firmware by performing the following steps:
1. Select the VC Domain with an incompatible status and click VC Domain Maintenance.
2. Upgrade the managed VC Domains to the minimum VCEM supported VC firmware version.
See the HP Insight Software Support Matrix or “Installation prerequisites” for the VCEM
supported VC firmware versions.
3. Click Complete VC Domain Maintenance to close the operation.
4. Upgrade the VC Domain Group firmware mode to the minimum VCEM supported VC firmware.
For more information, see “Upgrading VC Domain Group firmware mode”.
