HP Virtual Connect Enterprise Manager 6.2 User Guide

NOTE: If the previous configuration used custom MAC, WWN, and Serial Number ranges,
then add the same ranges to the new setup before proceeding.
4. Create new VC Domain Groups mirroring the prefail configuration specifying the currently
working credentials.
NOTE: Unassigned server profiles, external MAC and WWN addresses, and serial numbers
are not recovered with this procedure.
Enclosure has a hardware failure and must be replaced
An enclosure that is being managed by VCEM indicates a hardware failure that requires
replacement.
When a Virtual Connect Ethernet Module is removed from an enclosure and placed in another,
its settings are automatically cleared and all domain configuration is lost, including any existing
server profiles.
To resolve this issue:
1. From the VCEM home page, click the VC Domains tab.
2. Select the VC Domain that has an enclosure problem.
3. Click Remove from VC Domain Group. Wait for the job to complete successfully.
4. Connect the new enclosure in the network. Verify the network and SAN connections wired to
the new enclosure are the same as the failed one.
5. From the interconnect bays of the failed enclosure, remove the VC/FC modules and place
them in the same rear-panel positions of the Interconnect Bays in the new enclosure.
6. From the failed enclosure, remove all blades and place them in the same front-panel positions
in the new enclosure.
7. To configure the VC Domain, see the HP Virtual Connect for c-Class BladeSystem User Guide.
8. Access the Onboard Administrator web interface for the enclosure to verify that the VC Domain
link in the bottom left correctly points to the VC Domain Manager IP address.
9. To find the new enclosure, run an Systems Insight Manager discovery against the Onboard
Administrator IP address.
10. From the VCEM home page, click the VC Domains tab.
11. Select the newly discovered VC Domain, and then click Add to VC Domain Group. Wait
for the job to complete successfully.
Replace VC modules in a VC Domain managed by VCEM
To replace a VC Ethernet module or a VC Fibre Channel module of a VC Domain managed by
VCEM, perform the following:
1. From the VCEM home page, click the VC Domains tab.
2. Select the VC Domain with the VC modules to be replaced.
3. Click Remove from VC Domain Group. Wait for the job to complete successfully.
4. Replace the VC modules from the enclosure rear interconnect bays. Verify that the network
and SAN connections that are wired to the new VC modules are the same as the old
connections.
5. If the primary VC Ethernet module was replaced, then you must configure the VC Domain
again through Virtual Connect. For more information about configuring the VC Domain, see
the HP Virtual Connect For c-Class BladeSystem User Guide.
112 Troubleshooting VCEM
