• Auto execution mode
Auto execution mode performs monitoring and tier relocation based on information collected
by monitoring at a specified constant frequency: from 0.5, 1, 2, 4, or 8 hours. All Auto
execution mode cycle frequencies have a starting point at midnight (00:00). For example, if
you select a 1 hour monitoring period, the starting times would be 00:00, 01:00, 02:00,
03:00, and so on.
As shown in the following table, the 24-hour monitoring cycle allows you to specify the times
of day to start and stop performance monitoring. The 24-hour monitoring cycle does not have
to start at midnight. Tier relocation begins at the end of each cycle. For more information, see
(page 264).
Finish TimesStart TimesMonitoring cycle (hours)
0.5 hours after the start time0.5 hours from 00:00 AM. For example
00:00, 00:30, and 01:00
0.5
1 hour after the start time1 hour from 00:00 AM. For example
00:00, 01:00, and 02:00
1
2 hours after the start time2 hours from 00:00 AM. For example
00:00, 02:00, and 04:00
2
4 hours after the start time4 hours from 00:00 AM. For example
00:00, 04:00, and 08:00
4
8 hours after the start time8 hours from 00:00 AM. For example
00:00, 08:00, and 16:00
8
Specified timeSpecified time24 (monitoring time period
can be specified)
If the setting of the monitoring cycle is changed, performance monitoring begins at the new
start time. The collection of monitoring information and tier relocation operations already in
progress are not interrupted when the setting is changed. The next operations are initiated at
the new start time.
For example. if the monitoring cycle is changed from 1 hour to 4 hours at 01:30 AM, the
collection of monitoring information and tier relocation in progress at 01:30 AM continues.
At 02:00 AM and 03:00 AM, however, monitoring information is not collected and tier
relocation is not performed. In this example, operations could begin again at 04:00 AM, the
start time of the next monitoring cycle.
Figure 5 Collection of monitoring data to tier relocation workflow in auto execution mode
