where
• calculated-entire-capacity-of-a-CV(slots) means the entire capacity of a CV
if the data protection level is set to the Enhanced mode on the SATA drive.
Management area capacity of a mainframe volume
Management area capacity (cyl)Emulation type
73380-3, 3380-3A, 3380-3B, 3380-3C,
7 cyl per 1,113 cyl3390-A
63390-3, 3390-3R, 3390-3A, 3390-3B, 3390-3C
03390-V
253390-9, 3390-9A, 3390-9B, 3390-9C
233390-L, 3390-LA, 3390-LB, 3390-LC
533390-M, 3390-MA, 3390-MB, 3390-MC
53390-1
Notes:
• The management area capacity of a mainframe volume is expressed in cylinders (Cyl).
• For a Compatible FlashCopy SE volume with a 3390-A emulation type, if you specify a value between 1 and
40,068 cylinders, the space required equals the sum of the specified value and 252 of 40,069 cylinders or more,
calculate the required free space with this formula:
40,320 cylinders + the value rounded up after the decimal point of *A × 1,120 cylinders
where *A = (the specified value - 40,068) ÷ 1,113 cylinders
Boundary values for RAID levels (Enhanced mode on SATA drives)
Boundary value (KB)Emulation type
RAID 6 (14D+2P)RAID 6 (6D+2P)RAID 5 (7D+1P)RAID 5 (3D+1P)RAID 1 (2D+2D)
103,93622,27225,9845,5681,8563390-xx
Notes:
• xx indicates one or more numbers or letters.
• Boundary values are expressed in kilobytes.
• A SATA drive supports 3390-xx emulation types for a mainframe system.
•
Boundary values for RAID levels (other than Enhanced mode on SATA drives)
Boundary values of external volumes are always one slot, regardless of RAID levels.
Boundary value (KB)Emulation type
RAID 6 (14D+2P)RAID 6 (6D+2P)RAID 5 (7D+1P)RAID 5 (3D+1P)RAID 1 (2D+2D)
-2,3042,6881,1527683380-xx
6,4962,7843,2481,3929283390-xx
Notes:
• xx indicates one or more numbers or letters.
• Boundary values are expressed in kilobytes.
VLL size calculations 39
