DescriptionItem
LDKC number.LDKC
Provides information about a host, where the number groups, from left to right,
indicate:
Host
• First: The Type/Model the type and model number of a host or a channel
extender.
• Second: The Node ID of a host or a channel extender.
• Third: The Logical Partition Number of the host.
• Fourth: The vendor of the host. Vendors include FJT (Fujitsu), IBM, HTC
(Hitachi), and CNT(Ex) for channel extender. If CNT(Ex)appears, the table row
indicates the type, model number, and node ID of a channel extender.
Specifies a host group that you want to register in the security group.Host Group
Lists security groups in which the specified host is registered.Security Group
• Security Group indicates the name of the security group.
• Security indicates whether the security settings in the security group are
Enabled or Disabled.
Host to Security Group Dialog Box 323
