DescriptionColumn
Volume ID (in hexadecimal from 00 to FF).LDEV
Note: A volume ID that ends in # (for example, 00#) indicates that the volume
is an external volume.
Emulation type of the volume.Emulation
Volume status:Attribute
• An asterisk (*) denotes a secondary volume (copy destination) for P9500
copy software.
• A plus symbol (+) denotes that one or more LU paths are assigned to the
volume.
Add/Change Security Group Dialog Box
The Add/Change Security Group dialog box opens when you select Add/Change from the pop-up
menu after you right-click a security group or the Security Group node in the tree view of the Volume
Security window. You can use this dialog box to:
• Create a security group and classify the security group as an access group or a pool group.
• Prevent data in volumes from being overwritten by copy operations.
• Rename security groups.
• Delete security groups.
