Hosts Table
This table provides information about hosts. The contents of the table depends on the selections
you make in the Security Group tree.
• If you select Storage System, LDKC:00, Security Group, Host Group, or LDEV Group, the table
shows information about all the hosts.
• If you select a security group, the table shows information about all the hosts that belong to
the selected security group.
• If you select a host group, the table shows information about all the hosts that belong to the
selected host group.
• If you select an LDEV group, the table displays nothing.
DescriptionColumn
Sequential number associated with a host or channel extender.No.
Type and model number of the host or channel extender.Type/Model
Node ID of the host or channel extender.SEQNUMBER
Logical partition number of a host.LPAR
Host vendor. Vendors include FJT (Fujitsu), IBM, HTC (Hitachi), and CNT(Ex). If
CNT(Ex) appears, the table row indicates the type, model number, and node ID
of a channel extender.
Vendor
LDEVs Table
This table provides information about volumes. The information available depends on the selection
in the Security Group tree.
• If you select a Storage System, Security Group, Host Group, or LDEV Group, the table shows
information about all the volumes that are accessible from the mainframe hosts.
• If you select a security group, the table shows information about all the volumes that belong
to the selected security group.
• If you select an LDEV group, the table shows information about all the volumes that belong to
the selected LDEV group.
• If you select a host group, the table displays nothing.
