DescriptionItem
Displays the minimum percentage that is allocated to tier 1 in the total capacity
to which tier relocation is performed. For a policy whose ID is from 0 to 5, a
hyphen (-) is displayed.
Tier1 Min(%)
Displays the maximum percentage that is allocated to tier 3 in the total capacity
to which tier relocation is performed. For a policy with an ID from 0 to 5, a
hyphen (-) is displayed.
Tier3 Max(%)
Displays the minimum percentage that is allocated to tier 3 in the total capacity
to which tier relocation is performed. For a policy whose ID is from 0 to 5, a
hyphen (-) is displayed.
Tier3 Min(%)
Displays the number of V-VOLs to which the tiering policy is set.Number of V-VOLs
Change Tiering Policy Window
Change Tiering Policy table
DescriptionItem
Displays the tiering policy name and policy ID.Tiering Policy
Select the maximum percentage that is allocated to tier 1 in the total capacity
for the tier relocation from 0 (%) to 100 (%). The setting value is needed to satisfy
either one of following conditions:
Tier1 Max(%)
Equal to Tier1 Min
Bigger than Tier1 Min
Select the minimum percentage that is allocated to tier 1 in the total capacity
for the tier relocation from 0 (%) to 100 (%). The setting value is needed to satisfy
either one of following conditions:
Tier1 Min(%)
Equal to Tier1 Max
Smaller than Tier1 Max
Change Tiering Policy Window 301
