DescriptionItem
Displays the tiering policy name and ID.Tiering Policy
• All(0): Policy set when all tiers in the pool are used.
• Level1(1) - Level31(31): One of the policies from Level1 to Level31 is set.
• Hyphen (-): V-VOL is not the Smart Tiers or Smart Tiers Z V-VOL.
Displays the new page assigned tier.New Page Assignment Tier
• High: High is set to V-VOL.
• Middle: Middle is set to V-VOL.
• Low: Low is set to V-VOL.
• Hyphen (-): V-VOL is not the Smart Tiers or Smart Tiers Z V-VOL.
Displays whether tier relocation is set to enable or disable. If the Smart Tiers or
Smart Tiers Z V-VOL is not used, a hyphen (-) is displayed.
Tier Relocation
Displays the relocation priority.Relocation Priority
• Prioritized: The priority is set to V-VOL.
• Blank: The priority is not set to V-VOL.
• Hyphen (-): V-VOL is not the Smart Tiers or Smart Tiers Z V-VOL or the tier
relocation function is disabled.
Displays the attribute of the LDEV.Attribute
• TSE: TSE-VOL.
• Hyphen (-): Volume in which the attribute is not defined.
296 Thin Provisioning Z and Smart Tiers Z GUI reference
