DescriptionItem
Displays the used and total pool capacity. If the pool consists of multiple
pool-VOLs, the sum of its capacities is displayed in the Total field.
Capacity - Used/Total
Displays the free and formatted pool capacity. If the pool consists of multiple
pool-VOLs, the sum of its capacities is displayed in the Total field.
Capacity - Free
Virtual Volume table
If you select a Thin Provisioning, Smart Tiers, Thin Provisioning Z, or a Smart Tiers Z pool, this table
is displayed.
DescriptionItem
Displays the LDEV identifier, which is the combination of LDKC, CU, and LDEV.LDEV ID
Displays the LDEV name.LDEV Name
Displays the pool management task being performed to the pool.Pool Management Task - Status
• Waiting for Rebalance: The rebalance process is being waited.
• Rebalancing: The rebalance process is being performed.
• Waiting for Relocation: The tier relocation process is being waited.
• Relocating: The tier relocation process is being performed.
• Waiting for Shrink: The pool shrinking process is being waited.
• Shrinking: The pool shrinking process is being performed.
• Hyphen (-): The pool management task is not being performed to the pool.
Displays V-VOL progress percentage (%) of the pool management task being
performed. A hyphen (-) is displayed when the pool management task is not
performed.
Pool Management Task - Progress(%)
Displays the V-VOL management task being performed to V-VOL.V-VOL Management Task - Status
• Reclaiming Zero Pages: The zero page reclaim processing that is being
performed.
• Waiting for Zero Page Reclaiming: The zero page reclaim processing
• Hyphen (-): The V-VOL management task is not being performed to V-VOL.
Displays the progress percentages (%) of the V-VOL management task being
performed. A hyphen (-) is displayed when the V-VOL management task is not
performed.
V-VOL Management Task -
Progress(%)
Displays the emulation type.Emulation Type
Displays the V-VOL capacity.Capacity - Total
Displays the V-VOL used capacity.Capacity - Used
The displayed value of Total might be larger than the displayed value of Used
due to following reasons:
• Used displays the used V-VOL capacity which is rounded up on each page.
• If the emulation type is 3390-A, the used capacity of V-VOL includes the
capacity of control cylinders (7 Cyl is required per 1,113 Cyl).
• If the emulation type is 3390-A and the TSE Attribute is set to Enable, the
used capacity of V-VOL includes the management area capacity.
Displays the V-VOL usage ratio.Capacity - Used(%)
