Selected Pool table
DescriptionItem
Displays the pool name and pool ID.Pool Name (ID)
Selected Pool Volumes table
DescriptionItem
Displays LDEV identifier, which is the combination of LDKC, CU, and LDEV.LDEV ID
Displays the LDEV name.LDEV Name
Displays the pool-VOL capacity.Capacity
Displays the parity group ID.Parity Group ID
Displays the RAID level.RAID Level
Mixed indicates multiple RAID levels exist in a pool.
Displays the hard disk drive type and RPM. When the volume is the external
volume, Drive Type displays External Storage and the value of the external LDEV
tier rank.
Drive Type/RPM
Displays the emulation type.Emulation Type
Edit Pools wizard
Edit Pools window
Use this window to edit pool properties. If you want to change multiple properties for a pool two
or more times, wait until the current task finishes, and then change the next settings. If you attempt
264 Thin Provisioning Z and Smart Tiers Z GUI reference
