DescriptionItem
Drive Type displays External Storage and the value of the external LDEV tier
rank.
Displays the pool threshold.User-Defined Threshold (%)
• Warning: Warning threshold is displayed.
• Depletion: Depletion threshold is displayed.
For a Fast Snap or Snapshot pool, a hyphen (-) is displayed for Depletion.
Displays subscription limit of the pool.Subscription Limit (%)
For Fast Snap or Snapshot pool, a hyphen (-) is displayed.
Displays the number of pool-VOLs.Number of Pool VOLs
Displays the Smart Tiers or Smart Tiers Z information.Smart Pool
• Monitoring Mode
If the continuous mode is enabled, Continuous Mode is displayed. If the
period mode is enabled, Period Mode is displayed.
• Tier Management
If Smart Tiers or Smart Tiers Z is enabled, Auto or Manual of performance
monitoring and tier relocation is displayed. If Smart Tiers or Smart Tiers Z is
disabled, a hyphen (-) is displayed.
• Cycle Time
Displays the cycle of performance monitoring and tier relocation. If Smart
Tiers or Smart Tiers Z is disabled, a hyphen (-) is displayed.
• Monitoring Period
Displays the time zone of performance monitoring when 24 Hours is selected
in the Cycle Time list. If Smart Tiers or Smart Tiers Z is disabled, a hyphen (-)
is displayed.
Displays the information of the buffer space for new page assignment to each
tier.
• Tier 1: If you make the Smart Tiers or Smart Tiers Z function available, the
buffer space for new page assignment to tier 1 is displayed. If you make the
Smart Tiers or Smart Tiers Z function unavailable, a hyphen (-) is displayed.
Buffer Space for New page
assignment (%)
• Tier 2: If you make the Smart Tiers or Smart Tiers Z function available, and
tier 2 exists, the buffer space for new page assignment to tier 2 is displayed.
If you make the Smart Tiers or Smart Tiers Z function unavailable, or tier 2
does not exist, a hyphen (-) is displayed.
• Tier 3: If you make the Smart Tiers or Smart Tiers Z function available, and
tier 3 exists, the buffer space for new page assignment to tier 3 is displayed.
If you make the Smart Tiers or Smart Tiers Z function unavailable, or tier 3
does not exist, a hyphen (-) is displayed.
Create Pools wizard 259
