Virtual Volumes tab
This tab is displayed unless you select a Fast Snap or Snapshot pool.
DescriptionItem
The LDEV identifier, which is the combination of LDKC, CU, and LDEV.LDEV ID
Displays the LDEV name.LDEV Name
Normal: Normal status.
Status
Blocked: Host cannot access a blocked volume.
Warning: Problem occurs in the volume.
Formatting: Volume is being formatted.
Preparing Quick Format: Volume is being prepared for quick formatting.
Quick Formatting: Volume is being quick-formatted.
Correction Access: Access attribute is being corrected.
Copying: Data in the volume is being copied.
Read Only: Data cannot be written to a read-only volume.
Shredding: Volume is being shredded.
Hyphen (-): Any status other than the above.
Displays the emulation type.Emulation Type
Displays the V-VOL capacity.Capacity - Total
Displays the V-VOL used capacity.Capacity - Used
The displayed value on Total might be larger than the displayed value on Used
due to following reasons:
• Used displays the used V-VOL capacity which is rounded up on each page.
• If the emulation type is 3390-A, the used capacity of V-VOL includes the
capacity of control cylinders (7 Cyl is required per 1,113 Cyl).
Displays the V-VOL usage level.Capacity - Used(%)
Displays the V-VOL capacity in the specified unit.Capacity
Total: Displays the V-VOL total capacity.
Used: Displays the V-VOL used capacity.
Used (%): Displays the V-VOL usage rate.
* The displayed value on Total might be larger than the displayed value on Used
due to following reasons:
• The used capacity of V-VOL includes the capacity of control cylinders (7 Cyl
is required per 1,113 Cyl).
• Used displays the used V-VOL capacity which is rounded up on each page.
Displays the number of alternate paths. A hyphen(-) is displayed for the Thin
Provisioning Z or Smart Tiers Z V-VOL.
Number of Paths
Displays the CLPR ID.CLPR
Displays the tiering policy name and ID.Tiering Policy
All(0): Policy set when all tiers in the pool are used.
Level1(1) - Level31(31): One of the policies from Level1 to Level31 is set.
Top window when selecting a pool under Pools 251
