DescriptionItem
If Smart Tiers or Smart Tiers Z is enabled, Auto or Manual is displayed. If Smart
Tiers or Smart Tiers Z is disabled, a hyphen (-) is displayed.
Tier Management
For a Fast Snap or Snapshot pool, a hyphen (-) is displayed.
Displays the cycle of performance monitoring and tier relocation. If Smart Tiers
or Smart Tiers Z is disabled, a hyphen (-) is displayed.
Cycle Time
Displays the time of starting and ending of performance monitoring. If Smart
Tiers or Smart Tiers Z is disabled, a hyphen (-) is displayed.
Monitoring Period
Displays the monitoring mode that is set for the pool. If the continuous mode is
enabled, Continuous Mode is displayed. If the period mode is enabled, Period
Monitoring Mode
Mode is displayed. If Smart Tiers or Smart Tiers Z is disabled, a hyphen (-) is
displayed.
Displays the status of pool monitoring.Monitoring Status
If the monitoring is being performed, In Progress is displayed. A hyphen (-) is
displayed other than this case.
Displays the latest monitoring data.Recent Monitor Data
• If the monitoring data exists, the monitoring period of time is displayed.
Example: 2010/11/15 00:00 - 2010/11/15 23:59
• If the monitoring data is being obtained, only the starting time is displayed.
Example: 2010/11/15 00:00 -
• If the latest monitoring data does not exist, a hyphen (-) is displayed.
Displays the pool management task being performed to the pool.Pool Management Task
• Waiting for Rebalance: The rebalance process is being waited.
• Rebalancing: The rebalance process is being performed.
• Waiting for Relocation: The tier relocation process is being waited.
• Relocating: The tier relocation process is being performed.
• Waiting for Shrink: The pool shrinking process is being waited.
• Shrinking: The pool shrinking process is being performed.
• Hyphen (-): The pool management task is not being performed to the pool.
If the Fast Snap or Snapshot pool is displayed, a hyphen (-) appears.
For details about the tier relocation, see the tier relocation log file. For details
about the table items of the tier relocation log file, see “Tier relocation log file
contents” (page 83).
Displays the status of the tier relocation processing.Relocation Result
In Progress: The status of Pool Management Task is Waiting for Relocation or
Relocating.
Completed: The tier relocation operation is not in progress, or the tier relocation
is complete.
Uncompleted (n% relocated): The tier relocation is suspended at the indicated
percentage progression.
Hyphen (-): The pool is not a Smart Tiers or Smart Tiers Z pool.
Top window when selecting a pool under Pools 249
