DescriptionItem
Blocked: The pool is full, or an error occurred in the pool, indicating that
the pool is blocked. If the pool is in both Warning and Blocked status, only
Blocked is displayed.
Displays the pool name and pool ID.Pool Name (ID)
Displays the LDEV ID and LDEV name of the pool-VOL which includes the pool
management area.
Pool VOL with System Area (Name)
For Snapshot, a hyphen (-) is displayed.
Displays the pool type.Pool Type
• For a Thin Provisioning pool, THP is displayed.
• For a Smart Tiers pool, Smart is displayed.
• For a Thin Provisioning Z pool, Mainframe THP is displayed.
• For a Smart Tiers Z pool, Mainframe Smart is displayed.
• For a Fast Snap pool, FS is displayed.
• For a Snapshot pool, SS is displayed.
Displays the RAID level. If multiple RAID levels exist in a pool, this field indicates
as Mixed.
RAID Level
Displays the hard disk drive type and RPM of the pool. If multiple drive types
or RPMs exist in a pool, this field indicates that drive types or RPMs are mixed.
Drive Type/RPM
When the volume is the external volume, Drive Type displays External Storage
and the value of the external LDEV tier rank.
Displays the CLPR set for the Fast Snap or Snapshot pool-VOLs. Displays in
ID:CLPR form.
CLPR
For Pool-VOLs other than the Fast Snap or Snapshot pool-VOL, a hyphen (-) is
displayed.
Displays whether the cache mode is enabled or disabled. For a configuration
other than external volume configuration, a hyphen (-) is displayed.
Cache Mode
Displays the number of pool-VOLs set for the pool, and the maximum number
of pool-VOLs that can be set for the pool.
Number of Pool VOLs
Displays the number of V-VOLs associated with the pool, and the maximum
number of V-VOLs that can be associated with the pool.
Number of V-VOLs
For a Fast Snap or Snapshot pool, a hyphen (-) is displayed.
Displays the number of primary volumes of the Fast Snap or Snapshot pairs.
When the applicable volume does not exist, a hyphen (-) is displayed.
Number of Primary VOLs
Displays the used and total pool capacity. If the pool consists of multiple
pool-VOLs, the sum of its capacities is displayed in the Total field.
Pool Capacity (Used/Total)
Displays the used and total V-VOL capacity. For a Fast Snap or Snapshot pool,
a hyphen (-) is displayed along with the used and total V-VOL capacity.
V-VOL Capacity (Used/Total)
Displays the subscription (Rate of total V-VOL capacity associated with a pool
to the pool capacity/Subscription that is set).
Subscription (Current/Limit)
For a Fast Snap or Snapshot pool, a hyphen (-) is displayed for Current or Limit.
Displays the user-defined threshold (Warning/Depletion).User-Defined Threshold
(Warning/Depletion)
For a Thin Provisioning or Smart Tiers pool, as for the pool with only one of
the user definition threshold set, the system threshold (fixed at 80%) is enabled.
If the user-defined threshold is 80% or less, the value is displayed in the Warning
column. If the user-defined threshold is 81% or more, the value is displayed in
the Depletion column. In this case, the other column displays a hyphen (-).
For a Fast Snap or Snapshot pool, a hyphen (-) is displayed for Depletion.
