DescriptionItem
For each value, if the Estimated Configurable capacity is zero, is displayed in
the cell.
• Estimated Configurable
2
THP: Displays the estimated pool capacity of Thin Provisioning and Smart Tiers.
Mainframe THP: Displays the estimated pool capacity of Thin Provisioning Z and
Smart Tiers Z.
FS: Displays the remaining physical pool capacity that is configurable for Fast Snap.
SS: Displays the remaining physical pool capacity that is configurable for Snapshot.
Displays information about the THP V-VOL capacity.V-VOL Capacity
1
• Allocated/Total
THP: In the Allocated field, total capacity of the Thin Provisioning and Smart Tiers
THP V-VOLs to which LU paths are allocated is displayed. In the Total field, total
capacity of the Thin Provisioning and Smart Tiers THP V-VOLs is displayed.
Mainframe THP: In each of the Allocated and Total fields, total capacity of the Thin
Provisioning Z and Smart Tiers Z THP V-VOLs is displayed.
For each value, if the Estimated Configurable capacity is zero, is displayed in
the cell.
• Estimated Configurable
2
THP: Displays the THP V-VOL estimated configurable capacity of Thin Provisioning
and Smart Tiers.
Mainframe THP: Displays the THP V-VOL estimated configurable capacity of Thin
Provisioning Z and Smart Tiers Z.
Licensed Capacity (Used /
Licensed)
• THP: Displays the licensed capacity of Thin Provisioning. Used displays the total
capacity of pools for Thin Provisioning and Smart Tiers,
• Mainframe THP: Displays the licensed capacity of Thin Provisioning Z. Used displays
the total capacity of pools for Thin Provisioning Z and Smart Tiers Z.
• FS: Displays the licensed capacity of the Fast Snap.
• SS: Displays the licensed capacity of Business Copy and Snapshot.
CAUTION: In the Licensed Capacity(Used/Licensed) field, the total capacity of the
system is displayed. The total capacity of the system includes capacities of LDEVs
assigned to each user and resources other than LDEVs. Therefore, the value displayed
as the "Used" Licensed Capacity (Used/ Licensed) might differ from the value of the
"Total" Pool Capacity.
Displays the total number of pools for Thin Provisioning, Smart Tiers, Fast Snap, Snapshot,
Thin Provisioning Z, and Smart Tiers Z.
Number of Pools
Displays the Edit Tiering Policies window.Edit Tiering Policies
Notes:
1. The total value of the Total cells under Capacity of each pool type in the Pools tab window and the total Used
capacity of the Pool Capacity in the Summary table are almost same, but small differences might occur.
The capacity used by the Mainframe THP volume is different from the capacity used by the THP volume. If the
pool-VOL or THP V-VOL for Thin Provisioning or Thin Provisioning Z is created, the estimated configurable pool
capacity and estimated configurable V-VOL capacity for both THP and Mainframe THP change. The estimated
capacity is calculated based on the configuration of current pools and THP V-VOL, and remaining capacity of the
shared memory.
2. The estimated configurable capacity of Thin Provisioning or Thin Provisioning Z is the estimate of the THP V-VOL
capacity or the pool capacity that can be created by using the remaining capacity of the shared memory after
deduction of the capacity of the shared memory used by the current pool and THP V-VOL. The values of the Estimated
Configurable Pool Capacity and the Estimated Configurable V-VOL Capacity can be used only as a guide, but are
not guaranteed to create pools and THP V-VOLs having the estimated configurable capacity. If the pool-VOL or THP
