DescriptionItem
The processor blade identifier.MP Blade ID
The cluster number of the processor blade.Cluster
Indicates whether automatic assignment of processor blades is in use.Auto Assignment
• Enabled: A processor blade is automatically assigned to resources
(logical devices, external volumes, and journal volumes).
• Disabled: A processor blade is not automatically assigned to resources.
Assign Processor Blade wizard
Use this wizard to assign a processor blade that will control selected resources.
Assign Processor Blade window
Use this window to select a processor blade to assign to an LDEV.
DescriptionItem
The change the processor blade assigned to the LDEV.Processor Blade
processor blade ID: The selected processor blade is assigned to the LDEV.
Assign Processor Blade Confirm window
Confirm proposed settings, name the task, and then click Apply. The task will be added to the
execution queue.
Assign Processor Blade wizard 239
